Word处理控件Aspose.Words功能演示：使用 C++ 在 Word 文档中添加或删除页眉和页脚

一、用于在 Word 文档中添加和删除页眉和页脚的 C++ API

要在 Word 文档中添加页眉和页脚，我们将使用Aspose.Words for C++ API。它是一个原生 C++ API，支持创建、读取和修改 Word 文档，无需安装 Microsoft Word。您可以通过NuGet安装 API，也可以直接从“下载”部分下载。

PM> Install-Package Aspose.Words.Cpp

二、使用 C++ 在 Word 文档中添加页眉和页脚

Word 文档中的页眉和页脚分为三个部分，即标题页、偶数页和奇数页。您可以为这些部分添加不同的页眉和页脚。此外，您还可以在页眉和页脚中添加图像和表格等元素。

在此示例中，我们将创建一个新的 Word 文档并为标题页添加不同的标题。我们将在后续页面中添加带有图像的页眉和带有表格的页脚。以下是在 Word 文档中添加页眉和页脚的步骤。

• 创建Document类的实例来表示 Word 文档。
• 使用之前创建的Document对象创建DocumentBuilder类的实例。
• 使用PageSetup->set_DifferentFirstPageHeaderFooter(bool value)方法指定您想要标题页的不同页眉和页脚。
• 设置标题文本的字体属性。
• 为后续页面创建页眉和页脚。
• 使用DocumentBuilder->InsertImage(System::SharedPtr System::Drawing::Image image, Aspose::Words::Drawing::RelativeHorizontalPosition horzPos, double left, Aspose::Words::Drawing::RelativeVerticalPosition在标题中添加图像vertPos、双顶、双宽、双高、Aspose::Words::Drawing::WrapType wrapType) 方法。
• 在页脚中添加表格。
• 使用Document->Save(System::String fileName)方法保存 Word 文档。

以下示例代码演示了如何使用 C++ 在 Word 文档中添加页眉和页脚。

void CopyHeadersFootersFromPreviousSection(const System::SharedPtr<Section>& section){System::SharedPtr<Section> previousSection = System::DynamicCast<Section>(section->get_PreviousSibling());if (previousSection == nullptr){return;}section->get_HeadersFooters()->Clear();for (System::SharedPtr<Node> headerFooterNode : System::IterateOver(previousSection->get_HeadersFooters())){section->get_HeadersFooters()->Add(headerFooterNode->Clone(true));}}int main(){// Source and output directory paths.System::String inputDataDir = u"SourceDirectory";System::String outputDataDir = u"OutputDirectory";System::SharedPtr<Document> doc = System::MakeObject<Document>();System::SharedPtr<DocumentBuilder> builder = System::MakeObject<DocumentBuilder>(doc);System::SharedPtr<Section> currentSection = builder->get_CurrentSection();System::SharedPtr<PageSetup> pageSetup = currentSection->get_PageSetup();// Specify if we want headers/footers of the first page to be different from other pages.// You can also use PageSetup.OddAndEvenPagesHeaderFooter property to specify// Different headers/footers for odd and even pages.pageSetup->set_DifferentFirstPageHeaderFooter(true);// --- Create header for the first page. ---pageSetup->set_HeaderDistance(20);builder->MoveToHeaderFooter(HeaderFooterType::HeaderFirst);builder->get_ParagraphFormat()->set_Alignment(ParagraphAlignment::Center);// Set font properties for header text.builder->get_Font()->set_Name(u"Arial");builder->get_Font()->set_Bold(true);builder->get_Font()->set_Size(14);// Specify header title for the first page.builder->Write(u"Aspose.Words Header/Footer Creation Primer - Title Page.");// --- Create header for pages other than the first page. ---pageSetup->set_HeaderDistance(20);builder->MoveToHeaderFooter(HeaderFooterType::HeaderPrimary);// Insert absolutely positioned image into the top/left corner of the header.// Distance from the top/left edges of the page is set to 10 points.System::String imageFileName = inputDataDir + u"Desert.jpg";builder->InsertImage(imageFileName, RelativeHorizontalPosition::Page, 10, RelativeVerticalPosition::Page, 10, 50, 50, WrapType::Through);builder->get_ParagraphFormat()->set_Alignment(ParagraphAlignment::Right);// Specify header title for other pages.builder->Write(u"Aspose.Words Header/Footer Creation Primer.");// --- Create footer for pages other than the first page. ---builder->MoveToHeaderFooter(HeaderFooterType::FooterPrimary);// We use table with two cells to make one part of the text on the line (with page numbering)// To be aligned left, and the other part of the text (with copyright) to be aligned right.builder->StartTable();// Clear table borders.builder->get_CellFormat()->ClearFormatting();builder->InsertCell();// Set the first cell to 1/3 of the page width.builder->get_CellFormat()->set_PreferredWidth(PreferredWidth::FromPercent(100 / 3));// Insert page numbering text here.// It uses PAGE and NUMPAGES fields to auto calculate current page number and total number of pages.builder->Write(u"Page ");builder->InsertField(u"PAGE", u"");builder->Write(u" of ");builder->InsertField(u"NUMPAGES", u"");// Align this text to the left.builder->get_CurrentParagraph()->get_ParagraphFormat()->set_Alignment(ParagraphAlignment::Left);builder->InsertCell();// Set the second cell to 2/3 of the page width.builder->get_CellFormat()->set_PreferredWidth(PreferredWidth::FromPercent(100 * 2 / 3));builder->Write(u"(C) 2001 Aspose Pty Ltd. All rights reserved.");// Align this text to the right.builder->get_CurrentParagraph()->get_ParagraphFormat()->set_Alignment(ParagraphAlignment::Right);builder->EndRow();builder->EndTable();builder->MoveToDocumentEnd();// Add a page break to create a second page on which the primary headers/footers will be seen.builder->InsertBreak(BreakType::PageBreak);// Add a section break to create a third page with different page orientation.builder->InsertBreak(BreakType::SectionBreakNewPage);// Get the new section and its page setup.currentSection = builder->get_CurrentSection();pageSetup = currentSection->get_PageSetup();// Set page orientation of the new section to landscape.pageSetup->set_Orientation(Orientation::Landscape);// This section does not need different first page header/footer.// We need only one title page in the document. The header/footer for this page// has already been defined in the previous sectionpageSetup->set_DifferentFirstPageHeaderFooter(false);// This section displays headers/footers from the previous section by default.// Call currentSection.HeadersFooters.LinkToPrevious(false) to cancel this behaviour.// Page width is different for the new section and therefore we need to set// different cell widths for a footer table.currentSection->get_HeadersFooters()->LinkToPrevious(false);// If we want to use the already existing header/footer set for this section// but with some minor modifications then it may be expedient to copy headers/footers// from the previous section and apply the necessary modifications where we want them.CopyHeadersFootersFromPreviousSection(currentSection);// Find the footer that we want to change.System::SharedPtr<HeaderFooter> primaryFooter = currentSection->get_HeadersFooters()->idx_get(HeaderFooterType::FooterPrimary);System::SharedPtr<Row> row = primaryFooter->get_Tables()->idx_get(0)->get_FirstRow();row->get_FirstCell()->get_CellFormat()->set_PreferredWidth(PreferredWidth::FromPercent(100 / 3));row->get_LastCell()->get_CellFormat()->set_PreferredWidth(PreferredWidth::FromPercent(100 * 2 / 3));System::String outputPath = outputDataDir + u"CreateHeaderFooter.docx";// Save the resulting document.doc->Save(outputPath);}

三、使用 C++ 删除 Word 文档中的页眉和页脚

在上一节中，您学习了如何在 Word 文档中添加页眉和页脚。与添加类似，您可以根据需要从标题、偶数页和奇数页中删除页眉和页脚。以下是删除 Word 文档中所有页眉和页脚的步骤。

• 使用Document类加载 Word 文档。
• 创建HeaderFooter类的两个实例来表示页眉和页脚。
• 使用Section->get_HeadersFooters()->idx_get(Aspose::Words::HeaderFooterType headerFooterType)方法检索标题、偶数页和奇数页的页眉和页脚。
• 使用HeaderFooter->Remove()方法删除页眉和页脚。
• 使用Document->Save(System::String fileName)方法保存 Word 文档。

以下示例代码展示了如何使用 C++ 删除 Word 文档中的所有页眉和页脚。

// Source and output directory paths.System::String inputDataDir = u"SourceDirectory";System::String outputDataDir = u"OutputDirectory";System::SharedPtr<Document> doc = System::MakeObject<Document>(inputDataDir + u"SampleHeaderFooter.docx");for (System::SharedPtr<Section> section : System::IterateOver<System::SharedPtr<Section>>(doc)){// Up to three different header and footers are possible in a section (for first, even and odd pages).// We check and delete all of them.System::SharedPtr<HeaderFooter> header;System::SharedPtr<HeaderFooter> footer;header = section->get_HeadersFooters()->idx_get(HeaderFooterType::HeaderFirst);footer = section->get_HeadersFooters()->idx_get(HeaderFooterType::FooterFirst);if (header != nullptr){header->Remove();}if (footer != nullptr){footer->Remove();}// Primary header and footer is used for odd pages.header = section->get_HeadersFooters()->idx_get(HeaderFooterType::HeaderPrimary);footer = section->get_HeadersFooters()->idx_get(HeaderFooterType::FooterPrimary);if (header != nullptr){header->Remove();}if (footer != nullptr){footer->Remove();}header = section->get_HeadersFooters()->idx_get(HeaderFooterType::HeaderEven);footer = section->get_HeadersFooters()->idx_get(HeaderFooterType::FooterEven);if (header != nullptr){header->Remove();}if (footer != nullptr){footer->Remove();}}// Output file pathSystem::String outputPath = outputDataDir + u"RemoveFooters.docx";// Save the document.doc->Save(outputPath);

以上便是使用 C++ 在 Word 文档中添加或删除页眉和页脚详细步骤，要是您还有其他关于产品方面的问题，欢迎咨询我们，或者加入我们官方技术交流群。
